First App
We want to create a library app. A library has books that can be borrowed online. However, each book can only be borrowed once.
First we need to create a new project. Therefore, cd into the development directory.
PROJECT_NAME=Library
pip install django
django-admin startproject $PROJECT_NAME
cd ./$PROJECT_NAME
virtualenv venv
source venv/bin/activate
pip install simpledomcontrol
sed -i "s/INSTALLED_APPS = \[/INSTALLED_APPS = ['sdc_core',/g" ./$PROJECT_NAME/settings.py
python manage.py sdc_init
npm install
This creates a new folder named Library in your development directory. This directory is the new root project directory. It contains a Django project with all SDC extensions.
In order not to forget it, we should carry out the migration right away and create a super user.
python manage.py migrate
python manage.py createsuperuser
In the next step we need to create a new Django app. We call it main_app:
python manage.py startapp main_app
Do not forget to add main_app to the installed apps:
...
INSTALLED_APPS = ['daphne'] + INSTALLED_APPS + ['channels', 'sdc_tools', 'sdc_user', 'main_app']
...
./Library/Library/settings.py
Now that the main_app has been created, we can add a new SDC controller to the app. We call the controller dashboard:
python manage.py sdc_cc
New Controller
This is followed by the following CLI prompts:
Enter number to select an django App:
1 -> main_app
Enter number: [1] 1
Enter the name of the new controller (use snake_case): dashboard
The sdc_cc command creates the following files and links:
└─ your_chosen_directory/
└─ Library/
├─ Assets/
├─ src
├─ main_app -> ../../main_app/Assets/src/main_app
└─ ...
└─ ...
├─ main_app
├─ templates
└─ main_app
└─ sdc
└─ dashboard.html
├─ Assets/
├─ src
└─ main_app
├─ controller
└─ dashboard
├─ dashboard.html -> ../../../../../templates/main_app/sdc/dashboard.html
├─ dashboard.js
└─ dashboard.scss
├─ main_app.organizer.js
└─ main_app.organizer.scss
└─ ...
├─ Library
└─ ...
└─ ...
Next, we will add two more controllers: the ‘catalog’ controller and the ‘my_list’ controller.
python manage.py sdc_cc -a main_app -c catalog
python manage.py sdc_cc -a main_app -c my_list
These two commands are equivalent to the dashboard controller and generate JS, SCSS and HTML files for both controllers. Before we work with the two two controllers we set up the in app navigation.
DB Model
- Now that navigation through the available pages has been implemented, the next step is to fill the pages with content. To do this,
First, we need to create a new database table. For this, we will use an extension of the Django ORM (Object-Relational Mapper).
In SDC, these model classes do not need to be created manually. This can be done with a simple SDC command.
python manage.py sdc_new_model -a main_app -m Book
This command generates the following:
A new model class named Book in:
./Library/main_app/models.py
A new form class named BookForm in:
./Library/main_app/forms.py
Two new HTML view templates for the Book model:
./Library/Assets/src/main_app/models/Book/Book_details.html
./Library/Assets/src/main_app/models/Book/Book_list.html
see more: New model
Now, we need to populate. In this example, a book has a title, an author, text and a user relation field called ‘borrowed by’.
...
class Book(models.Model, SdcModel):
title = models.CharField(max_length=100)
author = models.CharField(max_length=100)
text = models.CharField(max_length=255, default=default_text)
borrowed_by = models.ForeignKey(User, null=True, on_delete=models.CASCADE)
class SearchForm(AbstractSearchForm):
"""A default search form used in the list view. You can delete it if you dont need it"""
CHOICES = (("title", "Title"), ("author", "Author"),)
PLACEHOLDER = "Title or Author"
DEFAULT_CHOICES = CHOICES[0][0]
SEARCH_FIELDS = ("title", "author")
class _SdcMeta:
"""Meta data information needed to manage all SDC operations."""
edit_form = "main_app.forms.BookForm"
create_form = "main_app.forms.BookForm"
html_list_template = "main_app/models/Book/Book_list.html"
html_detail_template = "main_app/models/Book/Book_details.html"
@classmethod
def render(cls, template_name, context=None, request=None, using=None):
if template_name == cls.SdcMeta.html_list_template:
sf = cls.SearchForm(data=context.get("filter", {}))
context = context | handle_search_form(context["instances"], sf, range=3)
return render_to_string(template_name=template_name, context=context, request=request, using=using)
@classmethod
def is_authorised(cls, user, action, obj):
return True
@classmethod
def get_queryset(cls, user, action, obj):
return cls.objects.all()
./Library/main_app/models.py
In SDC, the model is responsible for managing its own access rights. To ensure secure authorisation, edit the ‘is_authorised’ method.
...
class Book(models.Model, SdcModel):
...
@classmethod
def is_authorised(cls, user, action, obj):
match action:
case 'connect':
return True
case 'list_view':
return True
case 'detail_view':
return True
case 'load':
return True
case _: # edit_form, named_form, create_form, list_view, detail_view, save, create, upload, delete, load
return False
...
./Library/main_app/models.py
Since we do not need the forms for the books (User can not alter or create books), the Form classes can be ignored in this case. First, we should take care of the representation in the client.
Client-Side Data Models
The user should be able to browse the books as a list and read a details of the individual books. SDC offers a ListView and a DetailView for the client for this purpose.
{% load sdc_filter %}
<div class="search-view-container">
<sdc-search-view
data-range-size="{{ range_size }}"
data-range-start="{{ range|indexfilter:0 }}"
data-range-end="{{ range|indexfilter:1 }}"
data-total-count="{{ total_count }}"
data-remove-labels="true">
{% csrf_token %}
{% include "elements/inline_form.html" with form=search_form %}
</sdc-search-view>
</div>
{% if template_context.my_list %}
<h3>All books you have borrowed!</h3>
{% endif %}
<table class="table">
<tbody>
{% for instance in instances %}
<td>
<this.borrow_btn data-instance="{{ instance|serialize }}" data-user="{{ user.id }}"></this.borrow_btn>
</td>
<td>
<b>{{ instance.title }}</b><br>
by: {{ instance.author }}
</td>
<td>
<a class="btn btn-info navigation-links"
href="/*/*/sdc-detail-view&model={{ instance|to_class_name }}&pk={{ instance.pk }}">More</a>
<!-- Modal -->
</td>
</tr>
{% endfor %}
</tbody>
</table>
./Library/Assets/src/main_app/models/Books/Books_list.html
{% load sdc_filter %}
<div class="container-fluid">
<div class="row">
<div class="col-4">
<h3>{{instance.title}}</h3>
<h3>by: {{instance.author}}</h3>
</div>
<div class="col-8">
<p>{{instance.text}}</p>
</div>
</div>
</div>
./Library/Assets/src/main_app/models/Books/Books_details.html
General styling and HTML header
Let us now add a background images and a favicon to the static directory:
└─ your_chosen_directory/
└─ Library/
├─ Assets/
├─ static
├─ favicon.png
└─ lib.png
└─ ...
├─ Library
└─ ...
└─ ...
Then you need to add the background image to the index.style.scss
@use ...
body {
background-image: url("/static/img/lib.png");
background-repeat: no-repeat;
background-size: cover;
background-position: center;
.main-page-frame {
background-color: #ffffff44;
}
}
./Library/Assets/src/index.style.scss
and the favicon image to the template/base.html
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0, user-scalable=no">
...
<link href="{% static '/img/favicon.png' %}" rel="shortcut icon">
...
{% block scripts %}{% endblock %}
</head>
./Library/template/base.html
